| OPTICS |
| Colors:10W RGB full color |
| Laser source: diode. |
| Laser power /wavelength:1x3000mW Red(638nm) ;1x3000mW Green (520nm ); 4000mW Blue (445nm ) |
| Beam size: 7mm at aperture |
| Voltage: AC110~240V, 50/60Hz |
| Power consumption:200W |
| Divergence: <1.5mrad-full angle |
| FEATURES |
| External Modulation:Analog |
| Scanner system: 30kpps |
| Operation environment :Indoor |
| IP rate：IP20 |
| Control signal:DMX-512 international standard signal |
| Control mode:Music,auto,master-slave and DMX-512,ILDA Control |
| DMX Channel: 19/32CH |
| Cooling system:fan |
| SPECIFICATION |
| Dimension:34(L)*31(W)*17(H)cm NW:10KGS |
